ICON

2026 product lineup 12-strand HMPE rope

ICON is a DNV type‑approved, high‑performance 12‑strand rope manufactured from HMPE fibers, each strand individually treated using a rotating 360° kiss‑roller coating process to ensure uniform protection and performance stability.

Premium 12‑strand braided HMPE (UHMWPE) rope featuring ultra‑high breaking strength and excellent flotation.


Download Datasheet

customize color

Main color

DNV type-approved 12-strand platinum HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand white HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand orange HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand red HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand green HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand blue HMPE UHMWPE rope ICON with high breaking strength by Tatraropes
DNV type-approved 12-strand white HMPE UHMWPE rope ICON with high breaking strength by Tatraropes

Key benefits

  • Easy to splice
  • Ease of handling
  • Easy to inspect
  • High construction stability
  • Well balanced; 6 left and 6 right strands
  • Outsized surface contact – better abrasion resistance
  • No rotation under load
  • Single yarn coating, extended service life
ICON
Official Tatraropes works certificate representing internal quality inspection and load testing for synthetic ropes

Product features

  • Construction 12-strand plaited core

  • Fiber HMPE

  • Specific gravity 0,97 (floating)

  • UV resistance Excellent

  • Abrasion resistance Excellent

  • Acid resistance Excellent

  • Alkali resistance Excellent

  • Most chemicals resistance Excellent

  • Water resistance Excellent (0% absorption)

  • Heat resistance Low (145°C - 150°C melting)

  • Elongation Low (2-3% at break)

DOWNLOAD
materials

ICON – High Performance 12-Strand HMPE Rope

Diameter Mass MBL spliced MBL unspliced
(mm) (inch) (kg/m) (lbs/100 ft) (t) (kN) (lbs) (t) (kN) (lbs)
1 1/32" 0,001 0,0671 0,153 1,5 337 0,17 2 450
4 1/16" 0,003 0,202 0,454 4,4 989 0,504 5 1 124
2 1/32" 0,001 0,067 0,153 1,5 337 0,17 2 450
6 1/4“ 0,022 1,478 3,7 36,0 8 093 4,100 40 8 992
8 5/16“ 0,038 2,553 6,3 62,0 13 961 7,000 69 15 512
10 13/32“ 0,057 3,830 9,7 95,0 21 244 10,700 105 23 605
12 1/2“ 0,081 5,443 13,8 135,0 30 349 15,300 150 33 047
14 9/16“ 0,108 7,257 18,4 180,0 40 466 20,400 200 44 962
16 5/8“ 0,144 9,676 23,5 230,0 51 594 26,000 255 57 326
18 3/4“ 0,179 12,028 29,1 285,0 63 733 32,100 315 70 815
20 13/16“ 0,214 14,380 34,7 340,0 76 884 38,700 380 85 427
22 7/8“ 0,256 17,202 41,3 405,0 91 047 45,900 450 101 164
24 1 0,299 20,092 47,9 470,0 105 210 53,000 520 116 900
26 1_1/16“ 0,350 23,519 55,1 540,0 121 397 61,200 600 134 885
30 1_1/4“ 0,456 30,642 71,4 700,0 156 804 79,000 775 174 227
32 1_5/16“ 0,514 34,539 79,5 780,0 175 013 88,200 865 194 459
34 1_3/8“ 0,575 38,638 88,7 870,0 195 246 98,400 965 216 940
36 1_1/2“ 0,640 43,006 98,4 965,0 216 490 109,100 1 070 240 545
40 1_5/8“ 0,778 52,279 117,8 1 155,0 259 991 131,000 1 285 288 879
44 1_3/4“ 0,929 62,426 140,2 1 375,0 308 550 155,500 1 525 342 833
52 2_1/8“ 1,266 85,071 187,6 1 840,0 413 760 208,500 2 045 459 733
56 2_1/4“ 1,453 97,637 213,6 2 095,0 471 423 237,600 2 330 523 804
60 2_1/2“ 1,652 111,009 241,7 2 370,0 533 133 268,700 2 635 592 370
64 2_5/8“ 1,862 125,121 270,7 2 655,0 596 866 300,800 2 950 663 185
68 2_3/4“ 2,086 140,173 301,3 2 955,0 664 646 335,000 3 285 738 496
72 3 2,328 156,434 333,4 3 270,0 735 461 370,700 3 635 817 179
76 3_1/8“ 2,583 173,570 367,1 3 600,0 809 310 407,900 4 000 899 234
80 3_1/4“ 2,851 191,578 401,8 3 940,0 885 183 446,100 4 375 983 537
82 3_3/8“ 2,990 200,919 419,7 4 116,0 925 236 466,300 4 573 1 028 040
88 3_5/8“ 3,425 230,149 475,2 4 660,0 1 048 048 528,200 5 180 1 164 498
96 4 4,049 272,080 554,2 5 435,0 1 222 048 615,900 6 040 1 357 831
100 4_1/16“ 4,380 294,322 596,000 5 845,0 1 314 106 662,300 6 495 1 460 118
102 4_1/8“ 4,550 305,746 617,1 6 052,0 1 360 439 685,700 6 724 1 511 599
104 4_1/4“ 4,724 317,438 638,9 6 265,0 1 408 188 709,700 6 960 1 564 653
108 4_1/2“ 5,079 341,293 682,7 6 695,0 1 505 304 758,700 7 440 1 672 560
110 4_9/16“ 5,262 353,590 705,1 6 915,0 1 554 874 783,700 7 685 1 727 638
112 4_5/8“ 5,447 366,022 728,1 7 140,0 1 609 097 811,000 7 953 1 787 886
116 4_3/4“ 5,828 391,624 774,3 7 595,0 1 707 630 860,600 8 440 1 897 367
120 5 6,221 418,032 822,4 8 065,0 1 812 840 913,700 8 960 2 014 266
130 5_1/8" 7,256 487,581 947,1 9 289,0 2 088 219 1 052,400 10 321 2 320 219
