ICON DOUBLE GROMMET

2026 product lineup High Performance Grommets – up to MBL 2 595 ton

Supercharge your lifting operations with ICON Double Grommets - the ultimate HMPE solution engineered for maximum performance when single grommets simply aren't enough. Built from our high-performance ICON 12-strand and ICON HD ropes, every double grommet is constructed from genuine HMPE yarns, each individually coated using our revolutionary rotating 360° Kiss-roller technology. The result? Dramatically improved internal and external abrasion resistance, longer service life, and superior strength retention.


Precision-manufactured in accordance with our dedicated technical file based on the ISO 18264:2016 standard, each double grommet features expertly hand-spliced eyes with our proprietary positive locking tuck variant — delivering guaranteed anti-slip performance in every scenario.


Forget heavy, unwieldy steel wires. ICON Double Grommets are not only stronger and safer — they're more than 7 times lighter. And compared to standard fiber ropes, the compact diameter means 60% weight savings, reduced storage requirements, and dramatically easier handling. The double configuration amplifies load capacity and distribution, giving your team the ultimate edge in demanding lifting environments. All of this at a competitive market price, with full customization available to fit your exact needs.


Twice as strong. Twice as smart. That's ICON Double Grommets


Download Datasheet

customize color

Main color

HMPE double grommet

Key benefits

  • Less risk to the crew
  • Less injuries
  • 1/7 of weight steel wire ropes.
  • Easier handling
  • Faster operation
  • Less personnel needed
  • Higher lifting capacity
  • Less back injuries
  • No contact damage
  • No fraying or sharp edges
  • Superior bending flex fatigue
  • Easy to inspect and repair
ICON DOUBLE GROMMET

Product features

  • Construction 12-strand plaited core

  • Fiber HMPE

  • Specific gravity 0,97 (floating)

  • UV resistance Excellent

  • Abbrasion resistance Excellent

  • Acid resistance Excellent

  • Alkali resistance Excellent

  • Most chemicals resistance Excellent

  • Water resistance Excellent (0% absorption)

  • Heat resistance Low (145°C - 150°C melting)

  • Elongation Low (2-3% at break)

  • Chemical resistance Excellent

DOWNLOAD
materials

Diameter MBL spliced Work Load Limit (WLL) vertical and choker hitches SAFETY FACTOR 7:1
(mm) (inch) (t) (kN) (vertical t) (vertical kN)
6 1/4“ 13,05 128,0 1,86 18,29
8 5/16“ 22,52 220,8 3,22 31,54
10 13/32“ 34,26 336,0 4,89 48,00
12 1/2“ 48,95 480,0 6,99 68,57
14 9/16“ 65,26 640,0 9,32 91,43
16 5/8“ 83,21 816,0 11,89 116,57
18 3/4“ 102,79 1 008,0 14,68 144,00
20 13/16“ 124,00 1 216,0 17,71 173,71
22 7/8“ 146,84 1 440,0 20,98 205,71
24 1 169,68 1 664,0 24,24 237,71
26 1_1/16“ 195,78 1 920,0 27,97 274,29
28 1_1/8“ 223,52 2 192,0 31,93 313,14
30 1_1/4“ 252,89 2 480,0 36,13 354,29
32 1_5/16“ 282,26 2 768,0 40,32 395,43
34 1_3/8“ 314,89 3 088,0 44,98 441,14
36 1_1/2“ 349,15 3 424,0 49,88 489,14
38 1_9/16“ 383,42 3 760,0 54,77 537,14
40 1_5/8“ 419,31 4 112,0 59,90 587,43
44 1_3/4“ 497,62 4 880,0 71,09 697,14
48 2 579,20 5 680,0 82,74 811,43
52 2_1/8“ 667,31 6 544,0 95,33 934,86
56 2_1/4“ 760,30 7 456,0 108,61 1 065,14
60 2_1/2“ 859,83 8 432,0 122,83 1 204,57
64 2_5/8“ 962,62 9 440,0 137,52 1 348,57
68 2_3/4“ 1 071,93 10 512,0 153,13 1 501,71
72 3 1 186,14 11 632,0 169,45 1 661,71
76 3_1/8“ 1 305,24 12 800,0 186,46 1 828,57
80 3_1/4“ 1 427,61 14 000,0 203,94 2 000,00
84 3_3/8“ 1 556,50 15 264,0 222,36 2 180,57
88 3_5/8“ 1 696,80 16 576,0 241,47 2 368,00
92 4 1 837,11 17 932,8 261,24 2 561,83
96 4_1/16“ 1 970,92 19 328,0 281,56 2 761,14
100 4_1/8“ 2 119,39 20 784,0 302,77 2 969,14
102 4_1/4“ 2 194,11 21 516,8 313,44 3 073,83
104 4_1/2“ 2 271,12 22 272,0 324,45 3 181,71
108 4_9/16“ 2 427,75 23 808,0 346,82 3 401,14
112 4_5/8“ 2 595,15 25 449,6 370,74 3 635,66
